Filter Out Impurities. Soften Hard Water.
PAQOS Water Softener & Filter solutions are designed for water-treatment requirements involving filtration, hardness and mineral buildup.
Find Your Water Solution →
Better water. Better everyday use.
PAQOS Water Softener & Filter solutions are designed for water-treatment applications involving filtration, hardness and mineral buildup.
The supplied PAQOS material highlights Mitsubishi Chemical resin technology, Advanced Bead Technology and a stated 10+ years resin performance.
Understand the effects of hard water.
The supplied PAQOS material illustrates several everyday effects associated with hard water and mineral deposits.
Included in the supplied material as an effect associated with hard water.
Mineral buildup around fittings is illustrated in the supplied material.
Dry skin is included among the illustrated hard-water effects.
Hair fall is also shown in the supplied material.
Frizzy hair is another illustrated effect in the supplied material.
Corroded appliances are highlighted in the supplied hard-water material.
Better water. Better daily use.
A Luxurious Experience
Removal of calcium, magnesium and other mineral buildup is highlighted in the supplied material.
Improve System Efficiency
Scale buildup reduction and improved efficiency of plumbing and appliances are highlighted.
Saving Money on Maintenance
Reduced maintenance spending is listed among the supplied goals.
Increase Life of Appliances
Avoiding mineral deposits on fittings and appliances is highlighted.
Soft on the Skin
The supplied material presents soft water as a gentler experience.
Cleaner Shiny Surfaces
Reduced mineral deposits and water stains are included.
Filter first. Soften next.
Filtration and water softening are presented as separate treatment processes. Each process below has its own image and its own detailed technical explanation.
Water Filtration Process
The supplied PAQOS material describes filtration for flushing out debris and particles to support smooth water flow from showers and taps.
Water Softening Process
The supplied PAQOS illustration explains how hard-water minerals interact with resin beads during the softening process.
Water enters the water softener with dissolved minerals such as calcium and magnesium.
The supplied illustration shows negatively charged resin beads and positively charged sodium ions.
The supplied illustration shows calcium and magnesium attaching to the resin beads.
The supplied diagram shows the water becoming softened as calcium and magnesium are removed.
The final supplied illustration shows sodium ions in the output water.
Softener & Filter technical data.
Select a technical range to view the corresponding specifications.
AWS Automatic Softener
Specifications from the supplied PAQOS technical table.
| Model | Flow Max | 200 PPM | 400 PPM | Treated Hardness | Salt / Regeneration | Min. | Max. |
|---|---|---|---|---|---|---|---|
| AWS-50 | 4 m³/hr | 15 | 8 | <50 ppm | 10 kg | 1.5 | 3.5 |
| AWS-100 | 4 m³/hr | 30 | 15 | <50 ppm | 20 kg | 1.5 | 3.5 |
| AWS-125 | 4 m³/hr | 38 | 19 | <50 ppm | 25 kg | 1.5 | 3.5 |
| AWS-150 | 8 m³/hr | 45 | 23 | <50 ppm | 30 kg | 1.5 | 3.5 |
| AWS-200 | 10 m³/hr | 60 | 30 | <50 ppm | 40 kg | 1.5 | 3.5 |
AMF Automatic Filter
Specifications from the supplied PAQOS technical table.
| Model | Flow Max | Inlet | Outlet | Diameter | Height | Min. | Max. |
|---|---|---|---|---|---|---|---|
| AMF-50 | 4 m³/hr | 25 | 25 | 250 | 1350 | 1.5 | 3.5 |
| AMF-100 | 4 m³/hr | 25 | 25 | 325 | 1367 | 1.5 | 3.5 |
| AMF-125 | 4 m³/hr | 25 | 25 | 350 | 1635 | 1.5 | 3.5 |
| AMF-150 | 8 m³/hr | 25 | 25 | 400 | 1635 | 1.5 | 3.5 |
| AMF-200 | 10 m³/hr | 40 | 40 | 450 | 2060 | 1.5 | 3.5 |
Built around your water requirement.
Treatment selection can be considered according to source-water condition, hardness, flow and application.
Hard Water Treatment
Softening for water containing hardness associated with calcium and magnesium.
Particle Filtration
Filtration media for debris and particle reduction.
Whole House Treatment
Filtration and softening options for broader household requirements.
Groundwater Treatment
Iron-removal filtration is identified in the supplied material for groundwater.
A complete approach to water treatment.
PAQOS presents filtration and softening solutions for different water conditions and applications.
Treatment can be selected according to source-water condition and requirement.
Filtration and softening can be combined where required.
Automatic and manual configurations appear in the supplied material.
PAQOS also provides water, heat-pump and air solutions.
Softener & Filter FAQs.
Common questions about filtration, softening and the PAQOS range.
Explore more PAQOS solutions.
Discover complementary water and air solutions for homes, businesses and projects.
Ready for a better water experience?
Share your water source, hardness, flow requirement and application with the PAQOS team.
Talk to PAQOS →
